Integrations

Datadog

Kuberik reads Datadog monitors and incidents as health checks. A monitor that alerts after a deploy fails that deploy, and an open incident holds new deploys until it is resolved.

On this page
  1. What you need
  2. Give the controller credentials
  3. Fail a deploy on alerting monitors
  4. Hold deploys during an incident
  5. Use DatadogMonitor resources
  6. Select the checks from the Rollout
  7. How it works
  8. Troubleshoot
  9. Next steps

What you need

RequirementWhy
datadog-controllerTurns monitors and incidents into HealthCheck status
A Datadog API key and application keyFor the datadog and datadog-incidents classes. The application key needs monitors_read, plus incident_read for incidents and timeseries_query for the values the dashboard draws
The Datadog Operator (optional)Only for DatadogMonitor resources

Give the controller credentials

The controller reads one set of credentials for the whole cluster, from a Secret named datadog-credentials in the kuberik-system namespace. With the Helm chart, turn the controller on in your values:

values.yamlYAML
integrations:
  datadog:
    enabled: true

Without the chart, apply the controller on its own. Its install.yaml has no Namespace object, so kuberik-system must already exist:

Terminal
kubectl apply -f https://github.com/kuberik/datadog-controller/releases/latest/download/install.yaml

Then create the Secret and restart the controller so it reads it. Both install paths name the Deployment the same:

Terminal
kubectl -n kuberik-system create secret generic datadog-credentials \
  --from-literal=api-key=<your-api-key> \
  --from-literal=app-key=<your-app-key> \
  --from-literal=site=datadoghq.eu
kubectl -n kuberik-system rollout restart deployment datadog-controller-controller-manager

The controller maps the keys to DD_API_KEY, DD_APP_KEY and DD_SITE. Leave out site if your account is on datadoghq.com. The chart reads the Secret named in integrations.datadog.existingSecret (default datadog-credentials). Without credentials, every datadog and datadog-incidents HealthCheck stays Pending with the message datadog API credentials are not configured: set DD_API_KEY and DD_APP_KEY.

Fail a deploy on alerting monitors

A datadog HealthCheck selects monitors by tag, by ID, or both, and turns Unhealthy while any selected monitor alerts. Tag the monitors that should gate deploys, for example with service:hello-world and deploy-gate:true:

healthcheck-monitors.yamlYAML
apiVersion: kuberik.com/v1alpha1
kind: HealthCheck
metadata:
  name: hello-world-monitors
  namespace: hello-world
  labels:
    app: hello-world  # the Rollout selects this
  annotations:
    healthcheck.kuberik.com/datadog-monitor-tags: "service:hello-world,deploy-gate:true"
    healthcheck.kuberik.com/datadog-group-tags: "env:production"
spec:
  class: datadog
AnnotationValue
healthcheck.kuberik.com/datadog-monitor-tagsComma-separated tags. A monitor is selected when it carries all of them
healthcheck.kuberik.com/datadog-monitor-idsComma-separated monitor IDs, such as "123456,234567"
healthcheck.kuberik.com/datadog-group-tagsOptional. Narrows a multi-group monitor to the groups that match, such as the env:production group of a monitor grouped by env
healthcheck.kuberik.com/requeue-intervalOptional. How often to poll Datadog. Default 60s; values under 10s are ignored

Set at least one of datadog-monitor-tags and datadog-monitor-ids. Selecting by tag means a new monitor joins the gate when you tag it, and no monitor ever blocks a deploy by being missing: if no monitor carries the tags, the HealthCheck is Healthy and its message says nothing was evaluated.

Hold deploys during an incident

A datadog-incidents HealthCheck is Unhealthy while any active or stable Datadog incident matches a search query. It does not depend on any monitor.

healthcheck-incidents.yamlYAML
apiVersion: kuberik.com/v1alpha1
kind: HealthCheck
metadata:
  name: hello-world-incidents
  namespace: hello-world
  labels:
    app: hello-world
  annotations:
    healthcheck.kuberik.com/datadog-incident-query: "services:hello-world AND severity:(SEV-1 OR SEV-2)"
spec:
  class: datadog-incidents

The controller sends state:(active OR stable) AND <your query> to Datadog’s incident search. Join facets with AND, and put parentheses only around one facet’s values.

Use DatadogMonitor resources

If you manage monitors with the Datadog Operator, annotate a DatadogMonitor with kuberik.com/health-check: "true". The controller creates a HealthCheck named datadog-check-<monitor name> in the same namespace, with class datadog-monitor-crd and a copy of the monitor’s labels.

datadogmonitor.yamlYAML
apiVersion: datadoghq.com/v1alpha1
kind: DatadogMonitor
metadata:
  name: hello-world-error-rate
  namespace: hello-world
  labels:
    app: hello-world  # copied to the HealthCheck
  annotations:
    kuberik.com/health-check: "true"
spec:
  name: "hello-world error rate"
  type: metric alert
  query: "sum(last_5m):sum:hello_world.errors{env:production}.as_count() > 10"
  message: "hello-world returns errors after a deploy"

Removing the annotation deletes the generated HealthCheck. This path needs no Datadog credentials, because the Datadog Operator syncs the monitor state into the resource. The controller checks for the DatadogMonitor CRD once, at startup: if you install the Operator after the controller, restart the controller.

Select the checks from the Rollout

The Rollout picks up every HealthCheck whose labels match healthCheckSelector, in its own namespace unless you add a namespaceSelector:

rollout.yamlYAML
apiVersion: kuberik.com/v1alpha1
kind: Rollout
metadata:
  name: hello-world
  namespace: hello-world
spec:
  releaseSourceRef:
    name: hello-world
  bakeTime: 10m  # clear this long
  healthCheckSelector:
    selector:
      matchLabels:
        app: hello-world

Check that the HealthChecks report a status:

Terminal
kubectl -n hello-world get healthchecks -o custom-columns=NAME:.metadata.name,CLASS:.spec.class,STATUS:.status.status,MESSAGE:.status.message

How it works

datadog-controller turns monitors and incidents into HealthChecks; the Rollout reads only the HealthChecksTwo paths. Through the API: datadog-controller reads Datadog monitors and incidents with DD_API_KEY and DD_APP_KEY and writes HealthChecks of class datadog or datadog-incidents. Through the Datadog Operator: a DatadogMonitor resource synced by the operator and annotated kuberik.com/health-check: "true" makes datadog-controller write a HealthCheck datadog-check-<name> of class datadog-monitor-crd. The Rollout selects both with healthCheckSelector. A HealthCheck is Healthy, Unhealthy or Pending.Datadogmonitors,incidentsdatadog-controllerpolls every 60sDatadogMonitorsynced by theDatadog OperatorAPIHealthCheckdatadogdatadog-incidentsHealthCheckdatadog-check-<name>datadog-monitor-crdRollouthealthCheckSelectorHealthCheck statusHEALTHYUNHEALTHYPENDING datadog-controller turns monitors and incidents into HealthChecks; the Rollout reads only the HealthChecksTwo paths. Through the API: datadog-controller reads Datadog monitors and incidents with DD_API_KEY and DD_APP_KEY and writes HealthChecks of class datadog or datadog-incidents. Through the Datadog Operator: a DatadogMonitor resource synced by the operator and annotated kuberik.com/health-check: "true" makes datadog-controller write a HealthCheck datadog-check-<name> of class datadog-monitor-crd. The Rollout selects both with healthCheckSelector. A HealthCheck is Healthy, Unhealthy or Pending.Datadogmonitors, incidentsAPIdatadog-controllerpolls every 60sDatadogMonitorDatadog OperatorHealthCheckdatadog, datadog-incidentsHealthCheckdatadog-check-<name>datadog-monitor-crdRollouthealthCheckSelectorHealthCheck statusHEALTHYUNHEALTHYPENDING
datadog-controller turns monitors and incidents into HealthChecks; the Rollout reads only the HealthChecks.

The controller writes Datadog’s state into the HealthCheck status:

Datadog statedatadog classdatadog-monitor-crd class
OKHealthyHealthy
AlertUnhealthyUnhealthy
Warn, No Data, Skipped, IgnoredHealthyPending
API error or unknown monitor IDPendingNot applicable

The Rollout starts the bake once every selected HealthCheck is Healthy, and fails the deploy if any of them turns Unhealthy after the deploy started. While a check is Unhealthy, the Rollout also holds new automatic deploys and reports DeploymentBlocked with reason UnhealthyHealthChecks. See Verify with Health Checks for the full rules.

Troubleshoot

SymptomCauseFix
No datadog-check-* HealthCheck appears, and the controller log says DatadogMonitor CRD not installedThe Datadog Operator was installed after the controller startedRun kubectl -n kuberik-system rollout restart deployment datadog-controller-controller-manager
HealthCheck Pending: datadog API credentials are not configuredNo datadog-credentials Secret in the controller’s namespaceCreate the Secret, then restart the controller so it reads the new environment
HealthCheck Healthy: No Datadog monitors carry tags [...]No monitor has every listed tagTag the monitors in Datadog, or fix the annotation
HealthCheck Pending: get monitor <id>: ...The monitor ID does not exist, or the application key lacks monitors_readCheck the ID and the key’s scopes
No datadog-check-* HealthCheck appearsThe DatadogMonitor has no kuberik.com/health-check: "true" annotationAdd the annotation with the value in quotes
