Datadog
Kuberik reads Datadog monitors and incidents as health checks. A monitor that alerts after a deploy fails that deploy, and an open incident holds new deploys until it is resolved.
On this page
What you need
| Requirement | Why |
|---|---|
| datadog-controller | Turns monitors and incidents into HealthCheck status |
| A Datadog API key and application key | For the datadog and datadog-incidents classes. The application key needs monitors_read, plus incident_read for incidents and timeseries_query for the values the dashboard draws |
| The Datadog Operator (optional) | Only for DatadogMonitor resources |
Give the controller credentials
The controller reads one set of credentials for the whole cluster, from a Secret named datadog-credentials in the kuberik-system namespace. With the Helm chart, turn the controller on in your values:
integrations:
datadog:
enabled: trueWithout the chart, apply the controller on its own. Its install.yaml has no Namespace object, so kuberik-system must already exist:
kubectl apply -f https://github.com/kuberik/datadog-controller/releases/latest/download/install.yamlThen create the Secret and restart the controller so it reads it. Both install paths name the Deployment the same:
kubectl -n kuberik-system create secret generic datadog-credentials \
--from-literal=api-key=<your-api-key> \
--from-literal=app-key=<your-app-key> \
--from-literal=site=datadoghq.eu
kubectl -n kuberik-system rollout restart deployment datadog-controller-controller-managerThe controller maps the keys to DD_API_KEY, DD_APP_KEY and DD_SITE. Leave out site if your account is on datadoghq.com. The chart reads the Secret named in integrations.datadog.existingSecret (default datadog-credentials). Without credentials, every datadog and datadog-incidents HealthCheck stays Pending with the message datadog API credentials are not configured: set DD_API_KEY and DD_APP_KEY.
Fail a deploy on alerting monitors
A datadog HealthCheck selects monitors by tag, by ID, or both, and turns Unhealthy while any selected monitor alerts. Tag the monitors that should gate deploys, for example with service:hello-world and deploy-gate:true:
apiVersion: kuberik.com/v1alpha1
kind: HealthCheck
metadata:
name: hello-world-monitors
namespace: hello-world
labels:
app: hello-world # the Rollout selects this
annotations:
healthcheck.kuberik.com/datadog-monitor-tags: "service:hello-world,deploy-gate:true"
healthcheck.kuberik.com/datadog-group-tags: "env:production"
spec:
class: datadog| Annotation | Value |
|---|---|
healthcheck.kuberik.com/datadog-monitor-tags | Comma-separated tags. A monitor is selected when it carries all of them |
healthcheck.kuberik.com/datadog-monitor-ids | Comma-separated monitor IDs, such as "123456,234567" |
healthcheck.kuberik.com/datadog-group-tags | Optional. Narrows a multi-group monitor to the groups that match, such as the env:production group of a monitor grouped by env |
healthcheck.kuberik.com/requeue-interval | Optional. How often to poll Datadog. Default 60s; values under 10s are ignored |
Set at least one of datadog-monitor-tags and datadog-monitor-ids. Selecting by tag means a new monitor joins the gate when you tag it, and no monitor ever blocks a deploy by being missing: if no monitor carries the tags, the HealthCheck is Healthy and its message says nothing was evaluated.
Hold deploys during an incident
A datadog-incidents HealthCheck is Unhealthy while any active or stable Datadog incident matches a search query. It does not depend on any monitor.
apiVersion: kuberik.com/v1alpha1
kind: HealthCheck
metadata:
name: hello-world-incidents
namespace: hello-world
labels:
app: hello-world
annotations:
healthcheck.kuberik.com/datadog-incident-query: "services:hello-world AND severity:(SEV-1 OR SEV-2)"
spec:
class: datadog-incidentsThe controller sends state:(active OR stable) AND <your query> to Datadog’s incident search. Join facets with AND, and put parentheses only around one facet’s values.
Use DatadogMonitor resources
If you manage monitors with the Datadog Operator, annotate a DatadogMonitor with kuberik.com/health-check: "true". The controller creates a HealthCheck named datadog-check-<monitor name> in the same namespace, with class datadog-monitor-crd and a copy of the monitor’s labels.
apiVersion: datadoghq.com/v1alpha1
kind: DatadogMonitor
metadata:
name: hello-world-error-rate
namespace: hello-world
labels:
app: hello-world # copied to the HealthCheck
annotations:
kuberik.com/health-check: "true"
spec:
name: "hello-world error rate"
type: metric alert
query: "sum(last_5m):sum:hello_world.errors{env:production}.as_count() > 10"
message: "hello-world returns errors after a deploy"Removing the annotation deletes the generated HealthCheck. This path needs no Datadog credentials, because the Datadog Operator syncs the monitor state into the resource. The controller checks for the DatadogMonitor CRD once, at startup: if you install the Operator after the controller, restart the controller.
Select the checks from the Rollout
The Rollout picks up every HealthCheck whose labels match healthCheckSelector, in its own namespace unless you add a namespaceSelector:
apiVersion: kuberik.com/v1alpha1
kind: Rollout
metadata:
name: hello-world
namespace: hello-world
spec:
releaseSourceRef:
name: hello-world
bakeTime: 10m # clear this long
healthCheckSelector:
selector:
matchLabels:
app: hello-worldCheck that the HealthChecks report a status:
kubectl -n hello-world get healthchecks -o custom-columns=NAME:.metadata.name,CLASS:.spec.class,STATUS:.status.status,MESSAGE:.status.messageHow it works
The controller writes Datadog’s state into the HealthCheck status:
| Datadog state | datadog class | datadog-monitor-crd class |
|---|---|---|
OK | Healthy | Healthy |
Alert | Unhealthy | Unhealthy |
Warn, No Data, Skipped, Ignored | Healthy | Pending |
| API error or unknown monitor ID | Pending | Not applicable |
The Rollout starts the bake once every selected HealthCheck is Healthy, and fails the deploy if any of them turns Unhealthy after the deploy started. While a check is Unhealthy, the Rollout also holds new automatic deploys and reports DeploymentBlocked with reason UnhealthyHealthChecks. See Verify with Health Checks for the full rules.
Troubleshoot
| Symptom | Cause | Fix |
|---|---|---|
No datadog-check-* HealthCheck appears, and the controller log says DatadogMonitor CRD not installed | The Datadog Operator was installed after the controller started | Run kubectl -n kuberik-system rollout restart deployment datadog-controller-controller-manager |
HealthCheck Pending: datadog API credentials are not configured | No datadog-credentials Secret in the controller’s namespace | Create the Secret, then restart the controller so it reads the new environment |
HealthCheck Healthy: No Datadog monitors carry tags [...] | No monitor has every listed tag | Tag the monitors in Datadog, or fix the annotation |
HealthCheck Pending: get monitor <id>: ... | The monitor ID does not exist, or the application key lacks monitors_read | Check the ID and the key’s scopes |
No datadog-check-* HealthCheck appears | The DatadogMonitor has no kuberik.com/ annotation | Add the annotation with the value in quotes |
