Integrations

GitHub

Kuberik records every deploy as a GitHub deployment, which is how Environments in different clusters agree on what may go to production. The dashboard also signs people in to GitHub to show the commits and pull requests each deploy ships.

On this page
  1. What you need
  2. Create a token
  3. Store the token
  4. Point an Environment at the repository
  5. Show commit changes in the dashboard
    1. Create a GitHub App
    2. Install the app
    3. Create the Secret
    4. Restart the dashboard
    5. Sign in
  6. How it works
  7. Troubleshoot
  8. Next steps

What you need

ForYou needNotes
Environmentsenvironment-controllerThe Helm chart installs it with integrations.environment.enabled=true.
EnvironmentsA GitHub token per app namespaceClassic: repo_deployment for public repositories, repo for private ones. Fine-grained: Deployments: Read and write on the repository.
Dashboard changesA GitHub App, on the cluster that serves the dashboardRead-only access to Contents, Pull requests and Checks.

The token and the GitHub App are independent: set up either one without the other.

Create a token

The environment-controller only creates, lists and reads deployments and deployment statuses, so a token limited to deployments is enough.

Store the token

The controller reads the token from the key token of a Secret in the Environment’s own namespace. The Secret name defaults to github-token:

Terminal
kubectl create secret generic github-token -n hello-world \
  --from-literal=token=<your-token>

Create it in every cluster and namespace that has an Environment. To use another name, set it in the Environment’s backend.secret.

Point an Environment at the repository

backend.project is the repository the deployments are recorded in, as owner/repo:

environment.yamlYAML
apiVersion: environments.kuberik.com/v1alpha1
kind: Environment
metadata:
  name: hello-world-production
  namespace: hello-world
spec:
  rolloutRef:
    name: hello-world
  name: hello-world          # same in every tier
  environment: production
  backend:
    type: github
    project: acme/hello-world
    secret: github-token     # the default

Every deployment is created on the release’s commit, which the release controller reads from the image’s org.opencontainers.image.revision annotation. That commit must exist in backend.project, so build your images from that repository and set the annotation in CI.

Show commit changes in the dashboard

The dashboard can show what a deploy ships: the commits in the Change version dialog, and on the Changes page every merged pull request, where it stands per service and environment, and the check runs on its merge commit. Each person signs in through a GitHub App and sees only the repositories they can already read.

The Change version dialog deploying 4.44.0-44 of checkout-api to staging: the running build 4.43.0-43 and the held 4.44.0-44, Commits to deploy with two commits, their authors and shas, the Pin build switch, an optional note and the deploy buttonThe Change version dialog deploying 4.44.0-44 of checkout-api to staging: the running build 4.43.0-43 and the held 4.44.0-44, Commits to deploy with two commits, their authors and shas, the Pin build switch, an optional note and the deploy button
The commit list is read from GitHub with the signed-in person’s access.

Create a GitHub App

In the org that owns your source repositories, open Settings → Developer settings → GitHub Apps → New GitHub App:

FieldValue
Callback URLhttps://<dashboard-host>/api/auth/github/callback
Expire user authorization tokensUnchecked
Webhook → ActiveUnchecked
Repository permissionsContents, Pull requests and Checks: Read-only

<dashboard-host> is the host people open the dashboard on. With several clusters that is the hub; the other clusters send sign-ins to it and need no app.

Install the app

Choose Install App and install it on the org, for the repositories your Rollouts are built from.

Create the Secret

On the app’s General page, copy the Client ID and choose Generate a new client secret. The private key is not used.

Terminal
kubectl -n kuberik-system create secret generic github-app-credentials \
  --from-literal=clientId=<client-id> \
  --from-literal=clientSecret=<client-secret>

Restart the dashboard

When the Helm chart runs the dashboard (dashboard.enabled=true; it is off by default), it maps the Secret’s clientId and clientSecret keys to the dashboard’s GITHUB_APP_CLIENT_ID and GITHUB_APP_CLIENT_SECRET. The dashboard reads them at start, so restart it once the Secret exists:

Terminal
kubectl -n kuberik-system rollout restart deployment rollout-dashboard

The chart looks for a Secret named github-app-credentials. If yours has another name, set it in the chart values and upgrade:

values.yamlYAML
dashboard:
  githubApp:
    existingSecret: acme-github-app   # default github-app-credentials

Sign in

Open https://<dashboard-host>/api/auth/github/status in a browser tab where you are signed in to the dashboard. With dashboard sign-in turned on, a request without your session gets the sign-in redirect instead of this answer:

OutputJSON
{"configured":true,"connected":false}

The dashboard header now offers Connect GitHub. Sign in once; the commit lists fill in from then on.

The Changes page groups merged pull requests by the environment each has reached:

The In flight card of the Changes page: three pull requests grouped under the environment each has reached, two in development and one in productionThe In flight card of the Changes page: three pull requests grouped under the environment each has reached, two in development and one in production

How it works

For each entry in a Rollout’s history, the environment-controller creates a GitHub deployment on the release’s commit, with the task deploy:kuberik/<name> and the environment kuberik/<name>/<environment>. It then posts a status for the bake: in_progress while deploying and baking, success or failure when the bake ends, inactive when it is cancelled. The payload names the site and wave. Environments in other clusters read these deployments to decide which releases they may deploy, so the clusters never connect to each other.

The repository’s Environments page in GitHub shows the same history. The dashboard reads commits, pull requests and check runs with each person’s own GitHub sign-in, never with the controller’s token.

What Is Kuberik covers what keeps running while GitHub is down.

Troubleshoot

Errors from the GitHub side are in the environment-controller’s log:

Terminal
kubectl logs -n kuberik-system deployment/environment-controller-manager
SymptomCauseFix
failed to get GitHub token secret github-tokenThe Secret is not in the Environment’s namespace, or has another name.Create it in that namespace, or set backend.secret.
token key not found in secretThe Secret has no token key.Recreate it with --from-literal=token=<your-token>.
failed to create GitHub deploymentThe token cannot write deployments to the repository, or the release’s commit is not in it.Check the token’s scope and repository access, and the image’s revision annotation.
API rate limit exceeded for …The token spent its hourly GitHub API limit. Each gate keeps its last allowedVersions, so promotion stalls.Wait for the reset, or reconcile less often.
The dashboard shows Not configuredThe dashboard has no GITHUB_APP_CLIENT_ID or GITHUB_APP_CLIENT_SECRET.Create the Secret in kuberik-system, check dashboard.githubApp.existingSecret, and restart the dashboard.
GitHub says redirect_uri is not associated with this applicationThe app’s Callback URL does not match https://<dashboard-host>/api/auth/github/callback, scheme and host included.Correct the Callback URL.
